HIGH-PERFORMANCE AV RECEIVER - Enjoy 8K video and 3D audio via Denon AVR-X6800H AV Receiver. Get enveloped in sound with Dolby Atmos, DTS:X, IMAX Enhanced & Auro 3D, along with Dolby Surround, DTS Neural:X* &Auro-Matic upmixer to optimize legacy content
ADVANCED 8K HDMI VIDEO SECTION - With the capability of up to 13.4 channel processing, this AVR supports 8K HDMI, and advanced video formats like Dolby Vision, HDR, HLG, HDR10+, and Dynamic HDR pass-through & 8K upscaling on all 7 inputs and 2/3 outputs
MULTI-DIMENSIONAL AUDIO - In addition to Dolby Atmos, DTS:X, and Auro 3D, the HDMI receiver also supports Dolby Atmos Height Virtualization Technology that creates virtual height effects without the height channels for a truly immersive experience
NEXT-GEN GAMING - Enjoy smooth, lag-free gaming with spectacular imaging, reduced frame tearing with 8K/60Hz pass-through, Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) supported by this Denon receiver
AWARD-WINNING GUIDE - An on-screen quick setup guide walks you through clear instructions to connect your TV, and Audyssey MultEQ XT32 & SubEQ HT accurately calibrates all speakers in your home setup and tunes the AVR for an optimal listening experience
WIRELESS STREAMING - Enjoy the same song in all rooms or a different one in each room with built-in HEOS multi-room streaming. Stream music from popular services via Wi-Fi / Bluetooth, and get ultra hi-res audio with proprietary AL32 processing technology
VERSATILE CONNECTION OPTIONS - 7 HDMI In / 3 Out, each input selection covers various audio sources and devices (Phono, USB, & more). HDMI Out with eARC simplifies TV audio, and Pre-outs for 2-channel amp, and four subwoofers ensure a flexible audio setup
YOUR HOME AT YOUR FINGERTIPS - The home theater receiver features Domotz Pro & OvrC remote system monitoring and management technology programs, allowing custom integrators to remotely monitor and troubleshoot connected devices, and control them
Multichannel Surround
DTS HD Master / DTS:X / DTS:X Pro
Yes / Yes / Yes
DTS Neo:6 / DTS Neural:X
No / Yes
DTS Virtual:X
Yes
IMAX Enhanced
Yes
Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music
Yes / Yes / Yes / Yes
Dolby ProLogic Il / Dolby Surround
No / Yes
Auro 3D
Yes
360 Reality Audio / MPEG H
Yes / Yes
Audyssey DSX
No
Multichannel Stereo
Yes
Max. number of processing (preamp) channels
13.4
Sound Enhancements
Mono Block Power Amp Construction
Yes
Discrete Power Amplifier
Yes
D.D.S.C. HD Digital
Yes (32 bit)
Pure Direct
Yes
Gold Plated RCA Terminals
Yes
Clock Jitter Reducer
Yes
Alpha Processing
AL32 Processing Multichannel
Audyssey
MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume
Yes / Yes
Audyssey LFC
Yes
Dirac Live upgradability
Yes
Compressed Audio Restorer
Yes
Network
Media Server
Yes
HEOS Wireless Multi-Room Technology
Yes
Bluetooth Re-transmit for Bluetooth headphones
Yes (With volume control)
Alexa / Google Voice Assistant / Apple HomePod
Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC
Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV
Yes / Yes / Yes
Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
Yes / Yes / Yes
DSD Audio Streaming
Yes (2.8/5.6MHz)
FLAC HD 192/24
Yes
WAV 192/24
Yes
ALAC 192/24
Yes
Gapless playback
Yes (FLAC, WAV, ALAC ,DSD)
AirPlay Audio Streaming
Yes (AirPlay2)
Internet Radio
Yes (TuneIn)
Spotify Connect
Yes (connect)
Pandora
Yes
SiriusXM
Yes
Other Streaming Services
Amazon Music HD/ Amazon Music / TIDAL / Deezer / Soundcloud / Mood Mix
Roon Tested
Yes
HEOS App Control
Yes
Compatible with Remote APP for Smart Phones
Denon AVR Remote
Compatible with Remote APP for Tablets
Android / iOS / Amazon Kindle
Ethernet Ports
Yes
Wi-Fi
Yes
Bluetooth
Yes
HDMI
HDMI Inputs: Back, Front
7 / No
HDCP2.3 support
Yes
HDMI Outputs: Main, Zone
2 / 1
Video conversion Analog -> HDMI
Yes
HDMI to HDMI Scaling
1080P/4K to 8K
HDMI 2.1: 8K/60 Hz AB / 4K/120 Hz AB
Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out
7 / 2 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARC / InstaPrevue
Yes / Yes / Yes / Yes / No
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
Yes / Yes / Yes / Yes / Yes
ALLM (Auto Low Latency Mode) Pass-Through for Gaming
Yes
Variable Refresh Rate / Quick Flame Transport / Quick Media Switching
Yes / Yes / No
3D Signal Pass-Through
Yes
8K Signal Pass-Through, Scaling, GUI Overlay
Yes / Yes / Yes
4K Signal Pass-Through / Scaling / GUI Overlay
Yes / Yes / Yes
HDMI Pass-Though in Standby Mode
Yes
CEC
Yes
DSD Audio capability
Yes
Audio Return Channel
ARC, eARC
Auto LipSync
Yes
Multi-room / CI
Multi-Room Zones
3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog
Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out
Yes / Yes
Zone HDMI output from HDMI source
Yes
IP Control / RS232 Control / Web Control / App Control
Yes / Yes / Yes / Yes
Remote In / Out
Yes / Yes
DC Trigger output
3
HDMI Diagnostics
Yes
Others
Auto speaker setup by microphone
Audyssey MultEQ XT32 Dirac Live (upgrade)
Front Display
2 Line FLD
Graphic User Interface - GUI
Modern HD GUI
GUI Languages
3
Setup Assistent
Yes
Quick Select Plus, Quick Select
Yes / No
Firmware Update by Network / USB
Yes / Yes
Variable cross over
Yes
Optimized Bass Redirection
Yes
Bass Sync
Yes
ECO Mode
Yes
Auto Power Off
Yes
Sleep Timer
Yes
Inputs Outputs
VIDEO
Composite In / Out
2 / No
Component In / Out
1 / No
HDMI In / Out
7 / 3
Multi-Room Video Out: Video / HDMI
No / Yes
AUDIO
Analog In, Out
6 / No
Phono (MM) In
Yes
Digital in: Optical/Coaxial
2 / 2
Multi-Room Out: Analog/Digital
2 / No
Multichannel Pre-out
Yes (13.4)
Subwoofer Out
4 (independent)
OTHER
Speaker Terminal: Gold-Plated Screw / Regular Screw
Yes / No
Number of Speaker Terminals
13
Speaker A / B
assignable
Bi-amp drive
assignable
Multi-Room Speaker Terminal
assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB
No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone
Yes / No / No
USB Power Supply on Rear Panel
Yes
AM/FM Tuner
No
Specifications
Number of Power Amps
11
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)
140 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)
175 W
Power Output (6 ohm, 1 kHz, 1% 1ch Drive)
205 W
General
Metal Front Panel
Yes
System Remote Control
RC-1256
Pre-programmed / Learnable / LCD Display
Yes / No / No
Power Consumption in W
750
Power Consumption No-Sound (ECO On / Off) in W
65W / 110W
Standby Consumption in W
0.1
CEC Standby Consumption in W
0.5
Network Standby Consumption in W
Less than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
( Antenna:Vertical :(W x D x H) in mm)
【 w/o Antenna :(W x D x H) in mm】
434 × 389 × 167
(434 x 389 x 237)
(434 x 379 x 167)
Carton Dimensions (Packaging) (W x D x H) in mm)
531 x 465 x 303 (mm)
Weight in kg
15.6
Weight in kg (Packaging)
18.2
Power Supply
AC 230 V, 50/60 Hz
Speaker Impedance
4–16Ω/ohms
Pre-Amplifier Section
Input Sensitivity
200 mV
Frequency Response
10 Hz–100 kHz — +1, –3dB (Direct mode)
S/N Ratio
102dB (IHF-A weighted, Direct mode)
What's in the Box
Main unit, remote control, batteries, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
