:Specification
Turntable section Drive System Belt DriveMotor DC Motor
Speed 33-⅓ rpm, 45 rpmWow and Flutter 0.2% or less
Signal-to-Noise Ratio 67dB or higher (A-weighted, 20kHz LPF)
Platter Molded resin
Diameter of Platter 290mm
Tonearm section Type Static Balance, Straight
Effective Arm Length 207.9mmTracking Force 3.5g
Cartridge section Type VM (equivalent to MM)
Output Voltage 3.5mV (1kHz, 5cm/s)
Tracking Force 3.5g ±0.5g
Cartridge Weight 5.0g ±0.3g
Head-shell Weight 10g (including Screws, Nuts and Wires)
Phono Equalizer Amplifier Type of Amplifier MM type (On/Thru switchable)
Analog Output Connector RCA Pin jack (Gold-plated) × 1 pairOutput Voltage Phono/Line switchable
Phono Output 2.5mVLine Output 150mV
General Power AC 100-240V, 50/60Hz
Power Consumption 6.0W (less than 0.2W at Standby)
Overall Dimensions(W×H×D) 16.5" × 4.1" × 14.0"420 × 105 × 355 mm
Weight Approx. 7-¾ lbs. / 3.5 kg
Accessories- Rubber Mat, EP Adapter, VM-type Cartridge (AT3600L, Pre-installed), Platter, Dust Cover, Hinge × 2, RCA Audio Cable, AC Adapter (GPE053A-120050-Z), Owner's Manual (including Warranty Card for US/Canada)
