Features
Experience the high-fidelity audio of vinyl
Fully automatic belt-drive turntable operation with two speeds: 33-1/3, 45 RPM
Anti-resonance, die-cast aluminum platter
Redesigned tonearm base and headshell for improved tracking and reduced resonance
Integral Dual Magnet™ phono cartridge with replaceable diamond stylus (ATN3600L)
AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain
Built-in switchable phono pre-amplifier for phono- or line-level output
Includes: detachable RCA output cable (3.5 mm male to dual RCA male), 45 RPM adapter, and removable hinged dust cover
Specifications
Turntable
Type : fully automatic
Motor: DC servo-controlled
Drive Method : Belt-driveSpeeds 33-1/3 RPM, 45 RPM
Turntable Platter: AluminiumWow and Flutter Less than 0.25% (WTD) @ 3 kHz (JIS)
Signal-to-Noise Ratio >50 dB (DIN-B)
Output Level Pre-amp “PHONO”: 2.5 mV nominal at 1 kHz, 5 cm/sec
Pre-amp “LINE”: 150 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain : 36 dB nominal, RIAA equalized
Power Supply Requirements: 115/230V AC, 60/50 Hz
Dimensions : 359.5 mm x 97.5 mm x 373.3 mmWeight 2.6 kg
Accessories Included :3.5 mm (1/8") mini-plug (male) to dual RCA (male) output cable 45 RPM adapter Removable hinged dust cover
