Power Amplifier
Number of Powered Channels - 7
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) - 50 W
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)-
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) - 70 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) - 100 W
70% Guarantee - Yes
Discrete Power Amplifier - Yes
Amplifier Topology - Class A/B
Current Feedback Topology - No
Bi-Amp Drive - assignable
Multichannel Surround Technologies
DTS - DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby - Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Max Number of Processing (Preamp) Channels - 7.1
Inputs Outputs
HDMI In / Out - 6 / 1
Multi-Room Video Out via HDMI - No
Analog In / Fixed Level Out - 3 in / 0 out
Phono (MM) In - Yes
Digital In: Optical / Coaxial - 1 / 1
Multi-Room Out: analog / digital - 1 / 0
Multichannel Preamp Out - 7.2
Subwoofer Out - 2
7.1multichannel input - No
Number of Speaker Terminals - 7
Speaker A / B - assignable
Multi-Room Speaker Terminal - assignable
Front Inputs - USB-A
USB Audio / Made for iPod / Made for iPhone - Yes / No / No
AM/FM Tuner - Yes
HDMI
Total HDMI Inputs / No. Support 8K - 6 / 3
HDCP2.3 support - Yes
HDMI Outputs: Main / Zone - 1 / 0
Analog to HDMI Video Conversion - No
HDMI Upscaling - 1080P/4K to 8K
Max resolution @ framerate - 8K/60Hz, 4K/120Hz
Audio Return Channel - ARC, eARC
Video Dynamic Range - HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming - Yes
Variable Refresh Rate / Quick Frame Transport - Yes / Yes
HDMI Pass-Through in Standby Mode - Yes
CEC - Yes
DSD Audio over HDMI - No
Auto LipSync - Yes
Performance Technologies
Copper Plated Chassis - No
Toroidal Power Supply Transformer - No
Hyper Dynamic Amplifier Modules (HDAM) (List version) - No
Pure Direct Mode - Yes
Gold Plated RCA Terminals - No
Clock Jitter Reducer - No
Acoustic Room Correction
Audyssey - MultEQ
Audyssey Dynamic EQ / Dynamic Volume - Yes / Yes
Audyssey LFC - No
Dirac Live Support - No
Variable Cross Over - Yes
Optimized Bass Redirection - Yes
Bass Sync - No
Music File Support
Lossy Formats - MP3 / WMA / AAC
Lossless formats - FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio - 2.8 MHz / 5.6 MHz
Gapless Playback - FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2 - Yes
Network Audio Sharing - Yes
Streaming Services
HEOS Multi-room and Streaming - Yes
AirPlay Audio Streaming - AirPlay 2
Internet Radio - TuneIn
Spotify* - Spotify Connect
Pandora - No
SiriusXM - Yes
Other Streaming Services * - Amazon Music HD/
Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
Network Connectivity
Ethernet Ports - Yes
Wi-Fi (include version / band) - Yes
Bluetooth (Include version) - Yes
Bluetooth Re-transmit for Bluetooth headphones - Yes
Smart Home Integration and Control
Voice Assistant Compatibility - Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android) - Marantz AVR Remote App, HEOS
HEOS Multi-Room Integrated - Yes
HEOS Link Compatibility: IR/ IP - Yes /Yes
Multi-Room zones - 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog - 2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout - Yes / Yes
Zone HDMI Output from HDMI Source - No
Control Connectivity - IP Control / Web Control / App Control
IR Flasher In - Yes
Marantz Remote Bus - Yes
DC Trigger Output - 1
HDMI Diagnostics - Yes
Others
Front Display - port hole OLED
GUI Languages - 3
Setup Assistant - Yes
Smart Select on Remote - Yes
Firmware Update by Network / USB - Yes / Yes
ECO Mode - Yes
Auto Power off - Yes
Sleep Timer - Yes
General
Availabe colours - Black
Metal Front Panel - No
System Remote Control - RC050SR
Power Consumption in W - 250
Power Consumption No-Sound (ECO on/off) in W - 30 / 40
Standby Consumption in W - 0.2
CEC Standby Consumption in W - 0.5
Network Standby Consumption in W - Less than 2.0
Maximum Dimensions
W/o Antenna: (W x D x H) in mm - 442 x 384 x 109
Weight in kg - 8.7
What's in the box
Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
