AUDIO
Supported File Formats
MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS
Hi-Res formats - FLAC, MQA, WAV, AIFF
Native Sampling Rates
32 - 192 kHz
Bit Depths
16 - 24
Performance
Frequency Response: 45Hz - 20kHz
Distortion
THD+N, 0.030%
Power Output
150W total system power, bi-amplified
65W x 2 Woofer; 10W x 2 Tweeter
Speakers
2 x 5.25” (133mm) Woofers
2 x 1” (25mm) Tweeters
Supported Operating Systems
iOS, Android, Windows Vista, 7, 8, 10, macOS X 7-10
Free Internet Radio
TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise, LiveXLive, Radio.com
Supported Cloud Services
Spotify, Amazon Music HD, TIDAL, Deezer , Qobuz, HighResAudio (VAULT Required), Napster, KKBox, Bugs, Taihe Music ZONE, SoundMachine, IDAGIO, OraStream
Voice Control Integrations
Amazon Alexa & Google Assistant Skills
Integration Partners
Control4, RTI, Crestron, URC, push, iPort, ELAN, Lutron, roon, Airplay 2
Album Art
JPG
CONNECTIVITY
Network
Ethernet RJ45, GigE
Wi-Fi 5 (802.11ac, dual-band)
USB
1 x Type-A port for connection to USB memory sticks (Fat32 or NTFS formatted) and supported peripherals
1 x Type-B (mini) for product servicing
Audio Input
Combo - Toslink/3.5mm
Audio Output
Headphone output - 3.5 Stereo
Bluetooth Quality
Bluetooth 5.0 aptX HD wireless built-in
Bluetooth Connectivity
Two-Way (transmit & receive)
Power
Universal tri-pin AC Cord input (100 - 240AC)
GENERAL
Processor
ARM® CORTEX™ A9, 1 GHz
Unit Weight
5.05kg/11.11lbs
Gross Dimensions
420 x 198 x 192 mm
16.5 x 7.8 x 7.55 in
Power Consumption (Idle)
14 Watts
Accessories
2x AC power cords (Europe & North America)
Toslink Optical to 3.5mm Mini Adaptor
Ethernet Cable
Safety/Warranty Guide
Quick Setup Guide
Storage Environment
-10° C to 50° C, 20% to 80% relative humidity
Operating Environment
0° C to 40° C
Finish
Available in White or Black Matte
