AUDIO
Supported File Formats
MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS
Hi-Res formats - FLAC, MQA, WAV, AIFF
Native Sampling Rates
32 - 192 kHz
Bit Depths
16 - 24
Performance
Frequency Response: 45Hz - 20kHz
Distortion:
THD+N - 0.030%
Power Output
25 watts total system power at 0.030% THD
Speakers
1 x 4" (102mm), Woofer
1 x 1" 25mm, Tweeter
Supported Operating Systems
Plays music from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista 7-10, Apple Macintosh 7-10
Free Internet Radio
TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise, LiveXLive, Radio.com
Supported Cloud Services
Spotify, Amazon Music HD, TIDAL, Deezer , Qobuz, HighResAudio (VAULT Required), Napster, KKBox, Bugs, Taihe Music ZONE, SoundMachine, IDAGIO, OraStream
Voice Control Integrations
Amazon Alexa & Google Assistant Skills
Integration Partners
Control4, RTI, Crestron, URC, push, iPort, ELAN, Lutron, roon, Airplay 2
Album Art
JPG
CONNECTIVITY
Network
Ethernet RJ45, 100BaseT
Wi-Fi 5 (802.11ac, dual-band)
USB
1 x Type-A port for connection to USB memory sticks (Fat32 or NTFS formatted) and supported peripherals
1 x Type-B (mini) for product servicing
Audio Input
Combo - Toslink/3.5mm
Audio Output
Headphone output - 3.5 Stereo
Wireless
aptX® 4.1 Bluetooth wireless built-in
Power
Universal bi-pin AC Cord input (100 - 240AC)
GENERAL
Processor
ARM® CORTEX™ A9, 1 GHz
Unit Weight
1.23 kg / 2.7 lbs
Gross Dimensions
125 x 183 x 100 mm
4.92 x 7.2 x 3.9 in
Power Consumption (Idle)
14 Watts
Accessories
AC power cords (Europe or North America)
Toslink Optical to 3.5mm Mini Adaptor
Storage Environment
-10° C to 50° C, 20% to 80% relative humidity
Operating Environment
0° C to 40° C
Finish
Available in White or Black Matte
