Advanced AL32 Processing and Ultra Precision 192kHz/32bit D/A Converter - Digital recordings beautifully faithful to the original sound
DAC Master Clock Circuit Design - Jitter-free audio reproduction
Direct Mechanical Ground Construction - Minimizes unwanted vibration
Carefully designed construction, minimum signal paths and selected Hi-Fi parts - Preserves audio signal purity
Denon original drive mechanism with S.V.H. loader - Accurate pickup and decoding from all discs
Playback of CD and Super Audio CD; DSD (2.8 MHz / 5.6 MHz) files and PCM files up to 192 kHz / 24 bits recorded on DVD R/RW - Extended disc support for modern high-res audio
Separated digital and analogue power supply - Preserves audio signal purity
Pure Direct Mode - For clean output
Available in Premium Silver and Black - Perfectly matching the PMA-1700NE Integrated Amp
Technical information
SACD section
Channels 2 channels
Frequency response 2Hz - 50kHz (-3 dB)
Dynamic range 112 dB
Signal-to-noise ratio 119 dB
Total harmonic distortion 0.001% (1 kHz, audible range)
CD section
Channels 2 channels
Frequency response 2Hz - 20kHz
Dynamic range 101 dB
Signal-to-noise ratio 117 dB
Total harmonic distortion 0.0016% (1 kHz)
Output voltage 2.0 V (10 kohms)
Digital output 0.5 Vp - p/75 ohms
-15 to -21 dbm
660 nm
General
Power supply AC 230 V, 50/60 Hz
Power consumption 24 W (Standby 0.1 W)
Dimensions (W x H x D) 434 x 135 x 329 mm
Weight 8.2 kg
