Line In / Headphone Out
THD (20 Hz – 20 kHz)<0.03 % in 300 ohms at 2 V out
Signal-to-Noise Ratio>100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)Frequency response±0.3 dB (20 Hz – 20 kHz)
Output impedance8 ohms
Line In / Speaker Out
:Continuous output power into 8 ohms and 4 ohms
40W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
THD (20 Hz – 20 kHz)
<0.03 % (250 mW to 40 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio>95 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
>97 dB (A-weighted, 500 mV input, unity gain in 32 ohms)
Clipping power (at 1 kHz 0.1 % THD)>45 W in 8 ohms
>60 W in 4 ohmsIHF dynamic power8 ohms: 90 W
4 ohms: 120 W
2 ohms: 170 WDamping factor>200 (ref. 8 ohms, 1 kHz)
Frequency response±0.3 dB (20 Hz – 20 kHz, Tone Defeat ON)
Treble: ± 5dB at 10 kHz
Bass: ± 8 dB at 100 Hz
Channel separation>70 dB (1 kHz)Maximum input level4.3V (1 kHz THD 0.1%)Input sensitivity (for 40 W in 8 ohms)200 mVStandby power<0.5 W
Phono In / Speaker Out
THD (20 Hz – 20 kHz)<0.03 % (1 W to 40 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio>75 dB with IHF MM cartridge (A-weighted, ref. 5mV input 1 kHz and 1W output in 8 ohms)
Frequency response (RIAA deviation)+0.3 dB (20 Hz – 20 kHz, Tone Defeat ON)
Maximum input level71 mV (1 kHz THD 0.1%)Input sensitivity (for 40 W in 8 ohms2.95 mV
Dimension and Weight
Gross dimensions (W x H x D)17 1/8 x 3 9/16 x 11 1/4 inches
435 x 90 x 285 mm
Net weight5.5 kg (12.1 lbs)
Shipping weight6.4 kg (14.1 lbs)
